Hertz CP5.1K

Name: D-Class 5-Channel Amplifier 4x130W+1x510W
Brand: Hertz
SKU: CP5.1K
Price: 879.99 CAD
Availability: OutOfStock

We offer Free Shipping for this product if it's over $100

Out of stock

.price-ui--loading { display: block !important; opacity: 1 !important; }

$879.99$949.99

Channels	5 - 3
Amp class	D
POWER SUPPLY
Nominal power supply voltage (fuse)	11 ÷ 15 VDC (2 x 30 A)
Operating power supply voltage	9 ÷ 18 VDC
Idling current	1.90 A
Standby current draw	4 uA
Consumption, MIN load impedance (Max Musical Power)	48 A
Remote IN	4 ÷ 17 VDC (1 mA)
ART - Automatic Remote Turn on/off from SPK-IN (BTL radio only)	1.5 VDC
Efficiency	83%
AMPLIFIER STAGE
Distortion - THD @ 100 Hz, 70% Rated Power	0,01 % (F/R Ch) - 0,06 % (SUB Ch)
Damping factor @ 1 kHz, 1W	160 (F/R Ch) - 180 (SUB Ch)
Bandwidth @ -3 dB	10Hz ÷ 47kHz (F/R Ch) - 10Hz ÷ 500Hz (SUB Ch)
S/N ratio (A-weighted @ 1 V Input)	101 dBA (F/R Ch) - 116 dBA (SUB Ch)
Minimum load impedance
@ 5 Ch:	2 Ω
@ 3 Ch:	4 Ω + 4 Ω + 2 Ω
Adjustable Crossovers	yes
Output power (RMS) @ 1% THD:
5Ch @ 4Ω	80 W x 4 + 330 W x 1
5Ch @ 2Ω	130 W x 4 + 510 W x 1
3Ch @ 2Ω / 4Ω	260 W x 2 + 510 W x 1
2Ch @ 4Ω	260 W x 2 + 320 W x 1
Total Power	1030 W
Inputs	Pre-In / Speaker-In
Pre Out	Full Range (Front)
Pre-In sensitivity	0.32 ÷ 8 VRMS
Speaker-In sensitivity	1.6 ÷ 40 VRMS
Front Ch Hi-Pass	Full / 50-5000Hz 12dB/Oct.
Rear Ch Lo-Pass	Full / 50-5000Hz 12dB/Oct.
Sub Ch Lo-Pass	50 ÷ 500 Hz @ 24 dB/Oct.
Bass Boost 50Hz	0 ÷ 9 dB
Subsonic Hi-Pass	25 Hz @ 24 dB/Oct.
Sub Remote Volume Control	-20 ÷ 6 dB (Active on Sub Ch)

Channels	5 - 3
Amp class	D
POWER SUPPLY
Nominal power supply voltage (fuse)	11 ÷ 15 VDC (2 x 30 A)
Operating power supply voltage	9 ÷ 18 VDC
Idling current	1.90 A
Standby current draw	4 uA
Consumption, MIN load impedance (Max Musical Power)	48 A
Remote IN	4 ÷ 17 VDC (1 mA)
ART - Automatic Remote Turn on/off from SPK-IN (BTL radio only)	1.5 VDC
Efficiency	83%
AMPLIFIER STAGE
Distortion - THD @ 100 Hz, 70% Rated Power	0,01 % (F/R Ch) - 0,06 % (SUB Ch)
Damping factor @ 1 kHz, 1W	160 (F/R Ch) - 180 (SUB Ch)
Bandwidth @ -3 dB	10Hz ÷ 47kHz (F/R Ch) - 10Hz ÷ 500Hz (SUB Ch)
S/N ratio (A-weighted @ 1 V Input)	101 dBA (F/R Ch) - 116 dBA (SUB Ch)
Minimum load impedance
@ 5 Ch:	2 Ω
@ 3 Ch:	4 Ω + 4 Ω + 2 Ω
Adjustable Crossovers	yes
Output power (RMS) @ 1% THD:
5Ch @ 4Ω	80 W x 4 + 330 W x 1
5Ch @ 2Ω	130 W x 4 + 510 W x 1
3Ch @ 2Ω / 4Ω	260 W x 2 + 510 W x 1
2Ch @ 4Ω	260 W x 2 + 320 W x 1
Total Power	1030 W
Inputs	Pre-In / Speaker-In
Pre Out	Full Range (Front)
Pre-In sensitivity	0.32 ÷ 8 VRMS
Speaker-In sensitivity	1.6 ÷ 40 VRMS
Front Ch Hi-Pass	Full / 50-5000Hz 12dB/Oct.
Rear Ch Lo-Pass	Full / 50-5000Hz 12dB/Oct.
Sub Ch Lo-Pass	50 ÷ 500 Hz @ 24 dB/Oct.
Bass Boost 50Hz	0 ÷ 9 dB
Subsonic Hi-Pass	25 Hz @ 24 dB/Oct.
Sub Remote Volume Control	-20 ÷ 6 dB (Active on Sub Ch)
