XED Series 1-Channel Mono Block Class-D Amplifier

Cerwin-Vega XED6001D

Name: XED Series 1-Channel Mono Block Class-D Amplifier
Brand: Cerwin-Vega
SKU: XED6001D
Price: 239.95 CAD
Availability: OutOfStock

XED Series 1-Channel Mono Block Class-D Amplifier

We offer Free Shipping for this product if it's over $100

Out of stock

.price-ui--loading { display: block !important; opacity: 1 !important; }

$239.95$279.99

Upgrade your vehicle’s bass performance with the Cerwin-Vega XED6001D XED Series 1-Channel Monoblock Class-D Amplifier, a powerful and efficient amplifier engineered to deliver deep, impactful bass with the reliability and performance that Cerwin-Vega is known for. Designed with Cerwin-Vega’s Xtreme Energy Design, the XED6001D is built to drive subwoofers with authority while maintaining clean, distortion-free sound.

The XED6001D monoblock amplifier is specifically designed for subwoofer applications, delivering focused power to maximize low-frequency output and overall system performance. Whether you're upgrading a factory audio system or building a custom high-performance car audio setup, this amplifier provides the power and control needed to bring your music to life with strong, dynamic bass.

Utilizing advanced Class-D amplifier technology, the XED6001D provides high power efficiency while minimizing heat generation and electrical load. This efficient design ensures that the amplifier operates cooler and more reliably during extended listening sessions, allowing your audio system to maintain powerful output without sacrificing sound quality.

The amplifier features a lightweight aluminum chassis that serves as an effective heat sink, helping dissipate heat and maintain stable operating temperatures even under demanding conditions. This rugged construction ensures long-term durability while keeping the amplifier compact enough for flexible installation in a variety of vehicles.

Engineered with precision components and Cerwin-Vega’s commitment to performance, the XED Series amplifiers are built to handle high-output audio systems with ease. The XED6001D delivers tight, controlled bass response and clean signal reproduction, allowing your subwoofers to perform at their full potential.

Key Features:
• 1-channel monoblock Class-D car audio amplifier
• Designed for powerful subwoofer performance
• High-efficiency amplifier technology for strong output
• Lightweight aluminum chassis for effective heat dissipation
• Clean, distortion-free bass reproduction
• Ideal for aftermarket subwoofer system upgrades

The Cerwin-Vega XED6001D amplifier unleashes powerful bass energy, delivering the legendary Cerwin-Vega sound performance that transforms every drive into an immersive listening experience.

Specifications

Power Rating (RMS)

FREQUENCY RESPONSE (HZ): 35HZ - 350HZ
RMS POWER PER CHANNEL 4Ω 320W X 1
RMS POWER PER CHANNEL 2Ω 600W X 1

Power Supply

Power Supply: Full WPM
Power Supply Threshold: 10.0V-16.0V (DC)
Idle Current: (0.7A)

Distortion

THD 4 (100HZ @4Ω): 0.1%
S/N RATIO (A WEIGHTED @1W): -85dBA
S/N RATIO (A WEIGHTED @FP): -101.1dBA

Input Sensitivity

Low Level Input: 250mV-6.0V
High Level Input: 1.1V~>20.0V

Input Impedance

Low Level Input: 20KΩ
High Level Input: 100KΩ

Output Stage

Output Impedance: 2Ω
Damping Factor (50Hz@4Ω): >70
Bandwidth (-3db): 10Hz-250Hz

Crossover (1-12dB/Oct)

Variable High-Pass:
Variable low-Pass: 35Hz-250Hz
Variable Sub-Sonic: 10Hz-50HZ

Fuse Rating

2x30A (Inside)

Dimensions

Length x Width x Height: 7.1”x4.7”x1.8” (180mm x 120mm x 46.5mm)

FEATURES

Bass Boost: 0dB-12dB
LED Power/Protect Light Indicator
Bass Control Included
MFR #: XED6001D

The Cerwin-Vega XED6001D amplifier unleashes powerful bass energy, delivering the legendary Cerwin-Vega sound performance that transforms every drive into an immersive listening experience.

Specifications

Power Rating (RMS)

FREQUENCY RESPONSE (HZ): 35HZ - 350HZ
RMS POWER PER CHANNEL 4Ω 320W X 1
RMS POWER PER CHANNEL 2Ω 600W X 1

Power Supply

Power Supply: Full WPM
Power Supply Threshold: 10.0V-16.0V (DC)
Idle Current: (0.7A)

Distortion

THD 4 (100HZ @4Ω): 0.1%
S/N RATIO (A WEIGHTED @1W): -85dBA
S/N RATIO (A WEIGHTED @FP): -101.1dBA

Input Sensitivity

Low Level Input: 250mV-6.0V
High Level Input: 1.1V~>20.0V

Input Impedance

Low Level Input: 20KΩ
High Level Input: 100KΩ

Output Stage

Output Impedance: 2Ω
Damping Factor (50Hz@4Ω): >70
Bandwidth (-3db): 10Hz-250Hz

Crossover (1-12dB/Oct)

Variable High-Pass:
Variable low-Pass: 35Hz-250Hz
Variable Sub-Sonic: 10Hz-50HZ

Fuse Rating

2x30A (Inside)

Dimensions

Length x Width x Height: 7.1”x4.7”x1.8” (180mm x 120mm x 46.5mm)

FEATURES

Bass Boost: 0dB-12dB
LED Power/Protect Light Indicator
Bass Control Included
MFR #: XED6001D
