XED Series 4-Channel Full Range Class-D Amplifier

Cerwin-Vega XED4004D

Name: XED Series 4-Channel Full Range Class-D Amplifier
Brand: Cerwin-Vega
SKU: XED4004D
Price: 229.95 CAD
Availability: InStock

XED Series 4-Channel Full Range Class-D Amplifier

We offer Free Shipping for this product if it's over $100

In stock, ready to ship

.price-ui--loading { display: block !important; opacity: 1 !important; }

$229.95$259.99

Sale: - C$30.04 off

C$229.95

Upgrade your vehicle’s audio system with the Cerwin-Vega XED4004D XED Series 4-Channel Full Range Class-D Amplifier, a compact yet powerful amplifier designed to deliver clean sound, efficient performance, and the legendary Cerwin-Vega energy that car audio enthusiasts expect. Built with Cerwin-Vega’s Xtreme Energy Design, this amplifier provides the power and clarity needed to transform your driving experience into an immersive sound adventure.

The XED4004D 4-channel amplifier is engineered to power front and rear speakers with impressive clarity and dynamic range. Whether you're running component speakers, coaxial speakers, or bridging channels for additional power, this amplifier provides flexible system configuration and dependable output for a wide range of car audio setups.

Utilizing advanced Class-D amplifier technology, the XED4004D delivers high-efficiency power with minimal heat generation. This modern amplifier design maximizes output while reducing electrical strain and energy consumption, allowing your audio system to perform at higher levels without overheating or distortion.

The amplifier’s lightweight aluminum chassis not only gives it a sleek, durable design but also acts as a heat-dissipating structure that helps maintain optimal operating temperatures. This efficient thermal management ensures reliable performance during extended listening sessions or high-output audio playback.

Engineered with precision and built using quality internal components, the Cerwin-Vega XED Series amplifiers are designed to handle demanding audio systems while maintaining consistent performance. From detailed midrange frequencies to crisp highs and tight bass response, the XED4004D ensures your music is reproduced with clarity and power.

Key Features:
• 4-channel full range Class-D car audio amplifier
• High-efficiency digital amplifier technology for strong output
• Compact aluminum chassis for effective heat dissipation
• Flexible system configuration for speakers or bridged setups
• Clean, distortion-free sound performance
• Ideal for aftermarket car audio upgrades

The Cerwin-Vega XED4004D amplifier delivers powerful performance, energy-efficient operation, and the bold sound signature that makes Cerwin-Vega a leader in high-performance car audio.

Specifications

Power Rating (RMS)

FREQUENCY RESPONSE (HZ): 35HZ - 350HZ
RMS POWER PER CHANNEL 4Ω 60W X 4
RMS POWER PER CHANNEL 2Ω 90W X 4

Power Supply

Power Supply: Full WPM
Power Supply Threshold: 10.0V-16.0V (DC)
Idle Current: (0.7A)

Distortion

THD 4 (1KHZ @4Ω): 0.1%
S/N RATIO (A WEIGHTED @1W): -85dBA
S/N RATIO (A WEIGHTED @FP): -101.1dBA

Input Sensitivity

Low Level Input: 250mV-10.0V
High Level Input: 1.3V~>20.0V

Input Impedance

Low Level Input: 10KΩ
High Level Input: 100KΩ

Output Stage

Output Impedance: 2Ω
Damping Factor (50Hz@4Ω): >70
Bandwidth (-3db): 10Hz-30KHz

Crossover (1-12dB/Oct)

Variable High-Pass: 35Hz-250Hz
Variable low-Pass: 35Hz-250Hz

Fuse Rating (Inside)

30A

Dimensions

Length x Width x Height: 6.3”x4.7”x1.8” (160mm x 120mm x 46.5 mm)

FEATURES

LED Power/Protect Light Indicator
Selectable X-Over: High Pass/Flat/Low Pass
1-year Manufacturer's Warranty
MFR #: XED4004D

The Cerwin-Vega XED4004D amplifier delivers powerful performance, energy-efficient operation, and the bold sound signature that makes Cerwin-Vega a leader in high-performance car audio.

Specifications

Power Rating (RMS)

FREQUENCY RESPONSE (HZ): 35HZ - 350HZ
RMS POWER PER CHANNEL 4Ω 60W X 4
RMS POWER PER CHANNEL 2Ω 90W X 4

Power Supply

Power Supply: Full WPM
Power Supply Threshold: 10.0V-16.0V (DC)
Idle Current: (0.7A)

Distortion

THD 4 (1KHZ @4Ω): 0.1%
S/N RATIO (A WEIGHTED @1W): -85dBA
S/N RATIO (A WEIGHTED @FP): -101.1dBA

Input Sensitivity

Low Level Input: 250mV-10.0V
High Level Input: 1.3V~>20.0V

Input Impedance

Low Level Input: 10KΩ
High Level Input: 100KΩ

Output Stage

Output Impedance: 2Ω
Damping Factor (50Hz@4Ω): >70
Bandwidth (-3db): 10Hz-30KHz

Crossover (1-12dB/Oct)

Variable High-Pass: 35Hz-250Hz
Variable low-Pass: 35Hz-250Hz

Fuse Rating (Inside)

30A

Dimensions

Length x Width x Height: 6.3”x4.7”x1.8” (160mm x 120mm x 46.5 mm)

FEATURES

LED Power/Protect Light Indicator
Selectable X-Over: High Pass/Flat/Low Pass
1-year Manufacturer's Warranty
MFR #: XED4004D
